Production logistics: more productivity through inductive charging

With our inductive battery charging systems, you can increase the productivity of your production logistics by up to 30%. We enable flexible and fully automated intermediate charging (“in-process charging”) of your vehicle fleets without requiring major interventions in the infrastructure of your production and logistics environment. Smart data acquisition provides you with all relevant key figures for your energy management.

Consistent material availability at the installation site and maximum efficiency of processes – in production logistics, every second counts to ensure that production processes interlock smoothly. The focus here is on the automation of internal logistics and production with automated guided vehicle systems (AGVs), autonomous mobile robots (AMR), industrial trucks as well as the intelligent management and analysis of data. New energy solutions are needed to make economical and productivity-enhancing use of industry 4.0 route trains, autonomous production vehicles and the like

Fully automated charging processes for all vehicle types

With our inductive charging systems, you can sustainably increase the performance of your production logistics. The battery charging systems of the etaLINK series enable the “in-process charging” of your vehicle fleet. The energy solutions can be installed easily and flexibly via plug-and-play at highly frequented points in the warehouse layout, e.g. on walls, on the floor, on driveways, at parking areas or loading and unloading stations (source and sink), without interfering with the infrastructure. In this way, short downtimes of autonomous mobile robots in a cycle production or charging times of route trains can be used for “in-process charging”.

In this way, short downtimes of autonomous mobile robots in a cycle production or charging times of route trains can be used for “in-process charging”. If processes or sequences change, a new positioning can be implemented with a few simple steps. Your advantage: The system charges any type of vehicle regardless of voltage and charging current with only one stationary system. Time-consuming trips to charging areas are thus completely eliminated.

As soon as a route train, forklift, AGV or AMR drives to the charging station, the charging process starts fully automatically in less than a second. Thanks to the high efficiency of 93 %, even the shortest stops can be used for efficient energy supply. The result: unlike charging systems with plug or sliding connections, the energy level of the vehicles remains constant due to the many small intermediate charges. Longer charging phases, in which e.g. tugger trains are not productive, are a thing of the past. There is also no need for time-consuming battery changes and the necessary space-consuming infrastructure.

Logistic Loop without Wiferion in the e-commerce - warehouse - intralogistic - inductive charging - agvLogistic Loop with Wiferion in the e commerce - warehouse - intralogistic - inductive charging - agv - produktionslogistik - warehouse - automatisierte Routenzüge

Compared to traditional charging concepts in production logistics with conductor lines, as still frequently found in production lines with AMR integration, inductive point charging is convincing due to its high flexibility. A cost-intensive and static installation of the conductor lines in the hall floor is no longer necessary. In addition, the warehouse layout can be adapted at any time.

Save costs through reduced battery capacities

Since the energy level of the vehicles remains constantly high due to the short stops, only a small capacity range of the batteries is required. The required capacity of the battery used is reduced by up to 30% – and at the same time the costs for the acquisition of tugger trains and AMR are reduced.

Maintenance-free charging of AGV and AMR batteries

The fact that our inductive charging systems transfer energy without contact means that there is no need for abrasion or wear, as is the case with plug or sliding contacts. Our battery charging systems have IP65 certification.  This guarantees maintenance-free operation in 24/7 continuous use – even in demanding working areas where dust or dirt is generated. Outdoor installation is also possible.

Data evaluation for efficient logistics processes

Our battery and charging systems are a complete solution for energy supply and enable an evaluation of the data generated with our cloud-based software etaHUB. By systematically recording all energy data, you can control your processes with foresight.

The charging unit is connected to the battery via a CAN interface. In this way, all data regarding the energy level, operating times and vehicle conditions are recorded in real time. This allows you to implement industry 4.0 applications such as condition monitoring or predictive maintenance and to implement efficient energy and fleet management.

The benefits of inductive charging at a glance

Weather resistance

Weather resistance

Encapsulated system with IP 65 certification

One 4 All

One 4 All

One system for all voltages and charging currents

Position tolerance

Position tolerance

40mm in every direction

<1 sec to start

<1 sec to start

Directly on full power

Omnidirectional charging

Omnidirectional charging

Charge in any direction

Data transmission integrated

Data transmission integrated

All relevant data on a glance

No wear

No wear

No tearing points

No cleaning needed

No cleaning needed

Encapsulated system

No sparks

No sparks

Contactless charging

No wear and tear

No wear and tear

No loose components

See it in action or interested in our wireless charging solutions? Get in touch!

Our Products

etaLINK 3000

The wireless 3kW battery charging system

etaLINK 3000 - industrial wireless power - industrielles induktives laden - industrial wireless charging - ifoy winner - handling award winner
etaLINK 12000

Unleashed 12kW wireless power solution

etaLINK 12000 - industrial wireless charging agv and forklift - electric vehicles- 12kW - best product wireless power transfer- winner
etaSTORE

Your special batteries for wireless charging

Wiferion etaSTORE LFP - Battery - Batterie - Lithium Ion Battery - Industrial LiFEPo - Lithium Ionen Batterie für FTS, FFS, Flurförderzeuge und AGV
etaTRAY

Forklift retrofit for wireless charging

etaTRAY - 48v batterie trog - wireless charging with retrofit tray - kabelloses laden mit batterietrog - ffs, fts, routenzug - staplerbatterie - akku - industrie akku laden
